The main functions and features of Pad-Mounted transformers：

Pad-Mounted transformers are featured with small size, compact structure, reliable power supply and easy installation. Single or dual or ring network power supply can be realized. These products have double fuses and low operation costs.

The enclosures are electrostatic painted and highly wear resisting. They can be used for ring network, single and dual power supply and it is easy to switch, thereby improving power supply reliability. The green S11 series roll-core non-excitation full-sealed regulating transformers are energy efficient and have low noise. Amorphous alloy transformers can also be used at the users’ request. The high voltage load switch and fuse protector are located in the oil injection tank which is fully sealed. The low voltage chamber is equipped with electric energy meter, voltmeter, three-phase ampere meter and 4 outgoing line breakers, and reactive power compensation can also be installed as required.

The S11 series roll-core transformers are adopted. The no-load loss and noise are both low, respectively 30% - 40% and 7-10dB lower than that of S9.

Combined transformers have such outstanding properties as reliable power supply, reasonable structure, rapid installation, flexibility, easy operation, small size and low cost. Pad-Mounted transformers are suitable for both outdoor and indoor applications and are widely used in such places as industrial parks, residential areas, business centers and high-rise buildings, etc.
